Zirconia Ceramic Fixed Blade

Item : CSG00078

Details :

Ceramic Fixed Blade is mainly used in cutting polyester granular in the chemical industries. It can perfectly match with the underwater granular-cutting machines, which produced by Gernan Rieter Automatik GmbH or other factories.
◆Material Properties

Composition	Wt%	94.6% ZrO₂ 5.4%Y₂O₃
Density	g/cm³	>6.0
Hardness	GPa	>12
Thermal Expansion Coefficient	10^-6/k	9.6(20～400)
Modulus of Elasticity	GPa	200～250
Fracture Toughness	MPa·m^1/2	>9
Bending Strength	MPa	>1150
Grain Size	μm	<0.5
Thermal conductivity	w/(m·k)	2.5
